Panther X2 Helium
Inhouse product
-
$1,650.00 -
$899.00
-
$800.00
Reviews & Ratings
Panther X2 has a 4-core high-performance processor, ultra-low power consumption and ultra-long-distance IoT hotspot gateway. In addition, as an information converter for the LoRa communication protocol, Panther X2 acts as an end node.
Overview
As E-Sun Electronics Limited focuses on building a series of high-quality products in the Internet of Things field in the future, the team has been committed to continuously advancing the research, development, and iteration of Panther X series products. Following the successful launch of Panther X1, we completed the research and development of Panther X2 Hotspot and launched it to the public.
LoRa Specifications
LoRa Channel Plan | AS923 / EU868 / US915 |
Channel capacity | 8 channels |
LoRa output power | Maximum 30dBm |
Receiving sensitivity | -141 dBm @SF12 BW 125kHz; -127 dBm @SF7 BW 125 kHz; -111 dBm @FSK 50 kbps |
Platform
CPU | Quad-core Cortex-A55 up to 1.8GHz |
Memory | DDR4 4GB |
Storage | eMMC 32GB+ TF Card 64GB |
Wi-Fi radio | 2.4GHz 802.11 b/g/n |
BLE radio | BLE 5.2 |
Input Voltage | DC 12V 2A |
Connectors
LoRa Antenna | RP-SMA-K |
Ethernet | RJ45 Gigabit |
Power | 5.5*2.1mm, 12V DC |
Features
Panther X2 has a 4-core high-performance processor, ultra-low power consumption and ultra-long-distance IoT hotspot gateway. In addition, as an information converter for the LoRa communication protocol, Panther X2 acts as an end node
Secure and Reliable:
With a built-in ECC encryption chip, Panther X2 promises highly secure authentication and reliable connection
Easy set-up：
Easy steps to set up Panther X2
Customization:
Background configuration of data to enhance device efficiency
Ultra-low Power:
Panther X2 is equivalent to a 5W light bulb in power consumption, with daily consumption of 0.12kWh and a monthly cost of around $0.28
Wide Coverage:
Featuring enhanced 3dBi antenna, Panther X2 offers broader and more stable network coverage, which grants higher efficiency for hotspots to obtain HNT
Powered by Mature Hardware Solutions:
Powered by the quad-core Cortex-A55 1.8GHz processor; Semtech LoRa chip; 4G memory; 32GB EMMC and 64GB TF card
Large Storage:
With a faster running speed and quicker response offered by 4GB DDR4 RAM, Panther X2 is more efficient in acquiring HNT; its built-in eMMC 32GB + 64GB TF Card allows it to meet the need for the memory of the fast-growing Helium network
Broad Certification
Panther X2 Hotspot obtained CE, FCC, EAC and RCM Certification and is available worldwide, including Europe, United States, Australia and other countries
